PM-X Gold - Stainless Tool Steel Bar & Sheets

PM-X Gold - Stainless Tool Steel Bar & Sheets



PM-X Gold Stainless Tool Steel is a ground breaking steel designed specifically for the knife industry. It offers an impressive combination of toughness, wear resistance, and corrosion resistance—qualities rarely found together in high-performance blade steels. Unlike many other stainless steels, PM-X Gold achieves excellent hardness and edge retention without sacrificing toughness, making it highly versatile for a wide range of knife applications, from EDC to heavy-use outdoor blades.

The particle metallurgy process used to create PM-X Gold ensures uniform carbide distribution, contributing to its superior wear resistance, fine edge stability, and ease of sharpening.

Supplied hot rolled and annealed. This steel has a smooth surface and is soft in its annealed state, making it easy to cut, grind, drill, and file. Thickness may vary slightly from batch to batch.

Made by leading Chinese Steel Supplier (CSCJ)

Composition

• Carbon – 1.15%

• Chromium – 10.70%

• Vanadium – 3.90%

• Molybdenum – 2.10%

• Niobium – 2.00%

• Nitrogen – 0.13%

• Manganese – 0.50%

• Iron – Balance

Performance Characteristics

Toughness 8.5/10 – PM-X Gold is exceptionally tough for a stainless steel, outperforming many other high-end stainless steels like CPM S35VN or M390 in this category. It resists chipping and breaking, making it suitable for everything from small EDC knives to larger survival or tactical blades.

Edge retention 8/10 – PM-X Gold offers excellent edge retention, performing similarly to steels like CPM 20CV and M390. Its fine carbide structure helps maintain a sharp edge over time, and its balanced composition makes it easier to sharpen compared to higher-vanadium steels while still offering strong wear resistance.

Corrosion resistance 10/10 – One of PM-X Gold's standout features is its superior corrosion resistance. With nearly 11% chromium, it excels in harsh environments where exposure to moisture and corrosive elements would quickly degrade other steels. It is an ideal choice for knives used in marine, outdoor, or kitchen applications where corrosion resistance is critical.

Recommended Heat Treatment

• Coat blade in an anti-scale compound or seal in double crimped 310 or 309-grade stainless steel tool wrap

• Austenitise – Heat to 1080–1100°C and hold for 20–30 minutes

• Quench between aluminum plates, or oil quench

• Cryogenic Treatment – Immerse in liquid nitrogen or dry ice slurry for 1 hour or more to convert retained austenite to martensite and increase hardness

• Temper at 150–200°C for 2 hours, twice, depending on the desired hardness

Note: Cryogenic treatment is recommended for optimal performance, but PM-X Gold can also achieve great results without it. For maximum toughness, aim for lower austenitising temperatures and moderate tempering. Higher temperatures yield better wear resistance and edge retention, making it versatile for different blade applications.

Approximate As-Quenched Hardness Before Tempering:

• 1080–1100°C followed by liquid nitrogen – 63–65 HRC

• 1080–1100°C followed by dry ice – 62–64 HRC

Recommended Working Hardness
61–63 HRC
